Description
24V 250Wh lithium battery
Upgraded 24V 380Wh lithium battery
Upgrade a 24V 380Wh lithium battery
Specifications
Dimension
1850×780×1080mm
Wheel Base
1255mm
Seat Height
830mm
Dry/Curb Weight
45kg/57kg
Carrying Capacity
100kg
Ground Clearance
270mm
Front Fork Travel
Inverted coil spring hydraulic
front fork/ 200mm
Rear Shock/Wheel Travel
Intersect TR Multi-link rear suspention system with full adjustment 85/210mm
Max. Torque (on wheel)
266N.m
Power System
Power System
PMSM+FOC Sinewave Controller
Maximum Power(Motor)
8000W
Riding Mode
Sports + Eco mode
Assistance Functions
Regen(on sports mode)
Battery Type
60V/40Ah
21700 Lithium-ion removable battery pack
Throttle Curve
Two-stage Adjustable
Performance
Top Speed
75km/h
WMTC road
75km@40km/h
Charge Time（20%-80%）
2h
Frame&Tire
Tires Type
Front 70/100-19 Off-Road
Rear3.00-18 Off-Road
Frame Material
Frame Material
Forged aluminium alloy
WHATSAPP NUMBER # +44 7535 667090
Gallery
